EXACT8, 10XM8, 3 POLE 8000-80060-0000000
Bildet kan avvike fra produktet

EXACT8, 10XM8, 3 POLE

Conn.M12 12 pole
Artikkelnummer: 8000-80060-0000000
Vekt: 0.148 kg
Opprinnelsesland:  DE
Ikke på lager - Kontakt oss for leveringsdato
Find similar Product
Spørsmål
 Anbefal produkt
 Produktsammenlikning
Listepris per stykk:

Beskrivelse


10-way, 3-pole
M12 (12-pole)
Inline face or side mounting
Plastic housings with good resistance against chemicals and oils.
The resistance to aggressive media should be individually tested for your application. Further details on request.
Certificate
Certificate
Certificate
Certificate

Technical Data
Operating voltage 24 V DC
Operating current per contact max. 1.5 A
Protection IP67 inserted and tightened (EN 60529)
Housing Plastic, flame retardant
General data
Temperature range -20...+70 °C, depending on cable quality
Contact Layout
PIN 1 (+)
PIN 3 (-)
PIN 4 (NO)/(S1)
LED (green): Power / LED (yellow): (S1)
Product article number of manufacturer 8000-80060-0000000

ECLASS-6.0 27279219
ECLASS-6.1 27279219
ECLASS-7.0 27279219
ECLASS-8.0 27279219
ECLASS-9.0 27440108
ECLASS-10.1 27440111
ECLASS-11.1 27440111
ECLASS-12.0 27440111
ETIM-5.0 EC002585
EAN 4048879056731
Pakkestørrelse 1
Tolltariffnummer 85369010


Data om artikkel
  • Last ned Datablad
  • Last ned Approval: UL Listed CA 8000-80060-0000000_E201820_NRAQ7_ulc_z_a.pdf
  • Last ned Approval: UL Listed US 8000-80060-0000000_E201820-NRAQ_ul_z_b.pdf
  • Last ned Construction files: DXF 8000-80060-0000000_dxf_x_a.zip
  • Last ned Construction files: STP 8000-80060-0000000_stp_x_a.zip
  • Last ned Document: Installation guide 8000-84060-0000000_ina_2_14.pdf
  • Last ned Information: Certificate of conformity Murrelektronik GmbH 09-11-20_(3) RoHS REACh exception 6c 7cI_DoC_z_a.pdf
  • Last ned Information: Certificate of conformity Murrelektronik GmbH 20-10-21_(1) California Prop65 No Warning_DoC_z_b.pdf
  • Last ned Information: Certificate of conformity Murrelektronik GmbH 06-02-23_(3) China RoHS 2 25EEP_DoC_z_a.pdf
  • Last ned Information: Certificate of conformity UKCA 8000-80060-0000000_03-08.22_uk_z_b.pdf
  • Last ned Information: EU declaration of conformity 8000-80060-0000000_03-08.22_ce_z_c.pdf
  • Last ned Information: MTTF Report 8000-80060-0000000_SN29500(40°C)-BerechnungV1.4_mttf_p_a.pdf
