MVK-MPNIO DIO12 IOL4 IRT  7/8" 5pin
Product may differ from image

MVK-MPNIO DIO12 IOL4 IRT 7/8" 5pin

Art.No.: 55532
Weight: 0.966 kg
  In production
 Product Comparison
List price per piece:

You might also like

Digital inputs/outputs
DIO12 IOL4 (IRT)
Ethernet 10/100 Mbit/s; M12, D-coded
7/8", 5-pole, 2× max. 9 A
M12, 5-pole, A-coded
IO-Link Master V1.12
Connection cables are in the online shop under "Connection Technology".
Housing fully potted.
Input
Sensor supply US 24 V DC (EN 61131-2), max. 200 mA (M12 female)/max. 1 A (IO-Link female), short-circuit and overload protected
Type for 3-wire sensors or mechanical switches, PNP, IO-Link Devices
Output
Actuator supply UA 24 V DC (EN 61131-2), max. 9 A
Switching current per output max. 1.6 A (short-circuit and overload protected)
Lamp load 10 W
Connections
Fieldbus Ethernet 10/100 Mbit/s; M12, D-coded
Sensor-system/actuator supply 7/8", 5-pole, 2× max. 9 A
I/O ports M12, 5-pole, A-coded
General data
Protection IP67
Mounting method 2-hole screw mounting
Dimensions H×W×D 42×63×225 mm
Temperature range -25...+60 °C (storage temperature -25...+70 °C)
IO-Link
IO-Link 4× Master
Operating modes COM1; COM2; COM3 (automatic)
Transfer parameters 32 Byte (per IO-Link port)
Port Class Class A + B (not galvanically separated)
Specification IO-Link Master V1.12
PROFINET
FSU (Fast-Start-Up) max. 500 ms
Shared Device/Input yes, for 2 controls
PROFINET Netload Class III
Specification V2.3, Conformance Class C (IRT)
MRP yes
Addressing DCP
Parameterization
PIN 4 Input/Output (port X0...X7); IO-Link Master (port X4...X7)
PIN 2 Input/Output (port X0...X7); U-Actuator IO-Link Class B (port X4...X7)
Diagnostic
Communication status via LED
Diagnostic via LED per module and channel
Diagnostic via BUS per module and channel
Monitoring - under voltage yes
Monitoring - no voltage yes
Short-circuit and overload yes
Actuator warning per channel via LED and BUS
Cable break per port
Commercial data
country of origin DE
customs tariff number 85389099
EAN 4048879527583
eClass 27242604
Packaging unit 1
