Product may differ from image


IN: 100-240VAC OUT: 24-28VDC/10A
Art.No.: 85441
Weight: 0.85 kg
Out of Stock - Contact Us for Availability
 Product Comparison
List price per piece:
INPUT: 85...265 V AC/90...250 V DC
OUTPUT: 24...28 V DC
Current: 10 A
General data
Standards IEC 61010-2-201, EN 61204-3, EN 55011 B, EN 61000-3-2, SEMI F47
Mounting method DIN-rail mountable TH35 (EN 60715)
Temperature range -40...+60 °C, ...+70 °C derating (storage temperature -40...+80 °C)
Relative humidity 5...95%, no condensation
Protection IP20
Efficiency 92.8% (110 V AC); 94.3% (230 V AC)
Connection Push-In spring clamp terminals
Dimensions H×W×D 123×65×138 mm
Output voltage 24 V DC (SELV), ±1%; 24...28 V adjustable
Power Boost Iout N × 150% (min. 4 s)
LED display LED (green): OK; LED (red): overload, overheating or short-circuit
Output current 10 A
Mains failure bridging time min. 30 ms (100 V AC); 10 A (24 V DC)
Ripple max. 50 mV eff/rms
Spikes max. 200 mV ss/pp
Unit protection short-circuit and overload protected
Parallel usage/serial usage max. 5 units/max. 2 units
Input voltage 85...265 V AC/90...250 V DC
Input current 2.6 A (100 V AC); 1.1 A (240 V AC)
Inrush current after 1 ms max. 13 A
Power factor 0.95 (230 V AC)
Frequency 50...60 Hz
Input fuse (internal) 6.3 A (T)
Commercial data
country of origin CZ
customs tariff number 85044090
EAN 4048879381499
eClass 27049002
Packaging unit 1.000
Data Regarding Article:
  • Download Data Sheet
  • Download Approval: EAC 85441_RUC-DE.A301.B03872-2021.11.28_EAC_Z_A.PDF
  • Download Approval: UL Listed CA 85441_E200364-NMTR7_ULC_Z_A.PDF
  • Download Approval: UL Listed US 85441_E200364-NMTR_UL_Z_B.PDF
  • Download Approval: UL Registered CA 85441_E181433-QQGQ8_URC_Z_B.PDF
  • Download Approval: UL Registered US 85441_E181433-QQGQ2_UR_Z_B.PDF
  • Download Certificate: CB  85441_DK-34194-UL_CB_Z_A.PDF
  • Download Certificate: GL  85441_TAA00002EJ-2024.07.17_DNVGL_GL_Z_B.PDF
  • Download Construction files: DXF 85441_DXF_X_A.ZIP
  • Download Construction files: P8 85441_P8_2_50.ZIP
  • Download Construction files: STP 85441_STP_X_A.ZIP
  • Download Document: Installation guide 85441_INA_4_26.PDF
  • Download Document: Product data 85441_PD_X_12.ZIP
  • Download Information: EU declaration of conformity 85441_08-10.20_CE_Z_D.PDF
  • Download Information: MTBF Report 85441_SN29500(40°C)-BERECHNUNGV1.4_MTBF_P_D.PDF
  • Download Information: MTTF Report 85441_SN29500(40°C)-BERECHNUNGV1.4_MTTF_P_B.PDF
